Girth Gears offered find extensive application in different industry sectors including in sponge iron plants, steel & cement industry, mining industry, wind mills as well as in other industry sectors. These are made available in module range of 10 Module to 70 Module and in minimum diameters of 100 mm to 15000 mm. Further, these comprise maximum weight of 70 MT single pieces. Here the range of hardened & ground gear boxes/gears comprise Worm gear boxes, Helical / Double helical gears/gearboxes, Helical-Bevel gearboxes, Planetary Gearboxes and others.

CITIC IC Gear Cutting Machines include:

• Ø16m CNC Hobbing Machine
• Ø12m Gear Cutting Machine (Switzerland)
• Ø10m Hobbing Machine (Germany)
• Ø4m CNC High Speed Hobbing Machine (Germany)
• Ø1.6m Horizontal CHC Hobbing Machine (Germany)
• Ø5m CNC Profile Gear Grinding Machine (Germany)
• Ø2.8m CNC Profile Gear Grinding Machine (Germany)
• Ø1.25m CNC Profile Gear Grinding Machine (Germany)
• Ø1m CNC Profile Gear Grinding Machine (Germany)
• Ø0.8m CNC Profile Gear Grinding Machine (Germany)
• Automatic positioner

Module Range: 10 Module to 70 Module.

Diameter : Min 100 mm to16000 mm.

Weight : Max 120 MT single piece.

Hardened & Ground Gear Boxes/Gears:

• Worm gear boxes
• Helical / Double helical gears/gearboxes
• Helical-Bevel gearboxes
• Planetary Gearboxes
• Hardened & Ground Helical- bevel gears & Spiral-bevels gears/gearboxes.
• Rack & Pinions

Ratings:

• Min 3 hp to Max 1400 hp
• Splash / Forced lubrication type
• Send Enquiry

Rotary Kiln Girth Gears

We are leading supplier the Kiln Girth Gears for the various plants as listed below.

• Sponge Iron Plants 50TPD 100TPD 300TPD350TPD,500TPD,1000TPD
• Cement plants as per customer requirement
• Gears for phosphate mines, Alumina plant, kaolin-bentonite

Gear Cutting Capacity:

• 100mm diameter to 16000mm diameter
• 10Module to 70Module

The Kiln girth gears are available mainly in bi-part, four parts, 8 parts or multi segments as per the requirement and suitability with the application of gear.

In the field of grinding mill components, We supply mill heads,feed inlet,grinding roller,cement kiln riding ring, casting gears, shaft block .Also we supply mill shell of welding structures and fabrications.

Quality assurance documents
The following reports are to be submitted to Quality Assurance:
a. Chemistry report
b. Physical report
c. Heat treatment documents
CITIC HMC Q/HM 973.2-2007
Specification for Steel Castings for Grinding Mills
1 5
d. Ultrasonic inspection report (before and after repairs)
e. Magnetic particle inspection report (before and after repairs)
f. Dimensional report
g. Weld repair maps
h. Weld procedures and Procedure qualification record
i. Welder qualification
j. Nondestructive testing inspector qualification

Bevel Pinion Gear
